WEAVER SAFETY LANE BROCHURE FROM 1933

Weaver trademarked the term Safety Lane IN 1932.  Safety Lanes consisted of a Brake Tester, an Alignment Tester and a Headlight Tester.  More motor vehicles have been tested on Weaver Safety Lane Equipment, than any other manufacturer in the world. Weaver Safety Lane Equipment is still in production today








WEAVER BRAKE TESTER  & ALIGNMENT TESTER FLYER FROM 1952

1952 Weaver Brochure Featuring the Weaver WY-25 Combination Brake and Alignment Tester







WEAVER BRAKE TESTER AD FROM 1938

The Weaver WY-40 Brake Tester is Advertised in this Motor Magazine March 1938 AD.  This Line of Safety Lane Test Equipment is Still Manufactured Today.  Thousands of Installations Worldwide Since It's Inception are a Testimonial  to the Weaver Brake Tester Being the Most Widely Used and Accepted Brake Tester.







WEAVER SAFETY LANE EQUIPMENT  AD FROM 1937

September 1937 Advertisement from Motor Magazine.  The State of New Jersey installed 45 sets of Weaver Safety Lane Equipment to test every vehicle in the State twice a year.  Each Installation Included a WY-75 Brake Tester,  Heavy Duty Alignment Tester and the New Electric Eye Headlight Tester.







WEAVER SAFETY LANE EQUIPMENT  BROCHURE FROM 1932

The Weaver WX-10  Headlight Tester is featured in this brochure page from 1933.  This was Weavers very First Headlight Tester







WEAVER ALIGNMENT TESTER AD FROM 1931

Here is the Weaver Alignment Tester as Advertised in The Commercial Car Journal April  1931 AD.  This Line of Safety Lane Test Equipment is Still Manufactured Today.   This AD features the Weaver WJ-23 Drive Over Alignment Tester with a 1931 International Truck having it's Front End Checked.








WEAVER SAFETY LANE EQUIPMENT  AD FROM 1930

Weaver Safety Lane Equipment as Advertised in January 1930 Motor Magazine  AD.   Still Manufactured Today , the Brake Tester and Alignment Tester are featured.  This AD shows the Weaver WY-25 Brake Tester  and Weaver WJ-23  Alignment Tester .  In this Advertisement, the Weaver Headlight Tester is featured for the first time.







WEAVER HEADLIGHT TESTER BROCHURE FROM 1981

This 1981  Sales Brochure  detailed the features of the Weaver Headlight Tester Models







WEAVER SAFETY LANE EQUIPMENT  AD FROM 1939

Weaver Catalogue Advertisement  from August 1939 Featuring the Weaver WX-17 Headlight Tester and the Weaver WY-25 Brake Tester  The Term "Safety Lane" was Trademarked by Weaver.







Weaver Brake Tester and Alignment Tester  Safety Lane Inspection
New Jersey State Inspection Lane with Multiple Weaver Model WY-76  Combination Brake and Alignment Testers in 1952.		Washington DC Multiple Safety Lane Setup with Weaver Model WY-76  Combination Brake and Alignment Testers in 1952
Flat Bed Truck undergoing a Vehicle Safety Lane Inspection in 1952.    Weaver first introduced it's line of Brake Testers and Alignment Testers in the 1920's.  Since then millions of vehicles world-wide have been tested by this  equipment.  If fact Weaver is the World's most widely accepted and used Brake Tester.  The Inspection Lane Standard








WEAVER BROCHURE FROM 1950

Historic Occasion of the First  Public Automotive Safety Inspection in the USA at Springfield Illinois  in 1930.   During 1930 and 1931,  Public Safety Lane Inspection locations  were set up Coast to Coast in 291 different Cities.

The City of Memphis TN Installed Five  New Weaver Safety Lanes in 1950 - each Lane included a Combination Brake and Alignment Tester, plus a Headlight Tester.  The Cities first use of Weaver Safety Inspection Equipment began in 1930.







POPULAR MECHANIC ARTICLE FROM 1930

The December 1930 issue of Popular Mechanics Magazine featured an Article About Weaver Safety Lanes and a Nationwide Safety Campaign.

This photograph from Popular Mechanics Magazine page  980 shows a Safety Lane Inspection at Evanston Illinois using a Weaver Brake Tester, Alignment Testers and Weaver headlight Tester.  The Term "Safety Lane" was a Trademark of Weaver Manufacturing Company.







WEAVER BRAKE TESTER  PERFORMANCE CALCULATOR

Here is a Braking Effort Calculator from the Weaver Safety Lane Division in the Late 1960's.  Used with the Weaver Brake Tester, it allowed you to compute stopping distance, percent of front to rear braking effort and other calculations.









Documentation is available for this Product Manuals Available for these Models - Click Here Patent Office Data and Drawings - Brake Tester 11925 Patent Office Data and Drawings - Alignment Testter-1932 Patent Office Data and Drawings - Brake Tester -  1933 Patent Office Data and Drawings - Brake Tester 1957
